Nitomortar FC

Fosroc offers a comprehensive technical support service to specifiers, end users and contractors. It is also able to offer on-site technical assistance, an AutoCAD facility and dedicated specification assistance in locations all over the world.

• Fosroc products are guaranteed against defective materials and manufacture and are sold subject to its standard Conditions for the Supply of
• Goods and Service. All Fosroc datasheets are updated on a regular basis. It is the user’s responsibility to obtain the latest version.
• Head Office
• telephone: (+9714) 2039699 fax: (+9714) 2859649 email: agf@fosroc.com
• Regional offices
• Abu Dhabi, Al Gurg Fosroc telephone: 673 1779 fax: 673 1449 email: abudhabi@fosroc.com
• Bahrain, YBA Kanoo telephone: 17738200 fax: 17732828 email: bahrain@fosroc.com
• Kuwait, Boodai telephone: 4817618 fax: 4832124 email: kuwait@fosroc.com
• Oman, Al Amana telephone: 24815080 fax: 24817554 email: oman@fosroc.com
• Denotes the trademark of Fosroc International Limited
• †
• See separate data sheet

Nitomortar FC should be removed from tools, equipment and mixers with Fosroc Solvent 102* † immediately after use. Hardened material can only be removed mechanically. Estimating

12 months if kept in unopened tins and stored in a dry place away from direct sunlight. Storage conditions Store in dry conditions in the original, unopened containers. If stored at high temperatures the shelf life may be reduced to 4 to 6 months.

• Do not mix part packs under any circumstances.
• Nitomortar FC should not be exposed to moving water
• during application.
• Exposure to heavy rainfall prior to final set may result in
• surface scour.
• If any doubt arises concerning temperature or substrate
• condition, consult the local Fosroc office.

Nitomortar FC and Fosroc Solvent 102 should not come in contact with skin or eyes, or be swallowed. Ensure ade- quate ventilation and avoid inhalation of vapours. Some people are sensitive to resins, hardeners and solvents. Wear suitable protective clothing, gloves and eye/face protection. If working in confined areas, suitable respiratory protective equipment must be used. The use of barrier creams pro- vides additional skin protection. Should accidental skin contact occur, remove immediately with a resin removing cream followed by soap and water. Do not use solvent. In case of contact with eye, rinse immediately with plenty of clean water and seek medical advice. If swallowed seek medical attention immediately - do not induce vomiting. Fire Nitomortar FC is non-flammable. Fosroc Solvent 102 is flammable. Keep away from sources of ignition. No smoking. In the event of fire extinguish with CO 2 or foam. Do not use a water jet. Flash points Fosroc Solvent 102 : 33ºC For further information, refer to the product materials safety data sheet.

Fosroc manufactures a wide range of products specifically designed for the repair and refurbishment of damaged reinforced concrete. These include hand-placed and spray grade repair mortars, fluid micro-concretes, chemical-resist- ant epoxy mortars and a comprehensive package of protec- tive coatings.

It is suggested that the following list of equipment is adopted as a minimum requirement Protective clothing : Protective overalls : Good quality gloves, goggles and face mask Preparation equipment : Wire brush : Proprietary blasting equipment : Proprietary Degreaser Mixing equipment : Measuring jug : 1 KW slow speed drill, 400 or 500 rpm + Fosroc MR4 mixing paddle + suitably sized mixing vessel, for single bag mixing Application equipment : Hand application trowel 0r Scraper 0r Filling knife : Finishing sponge Application - points of note Fosroc operates a policy to encourage the use, where possible, of registered applicators, since the long term performance of the materials is dependent upon proper application. For contractors who wish to apply the materials themselves Fosroc is also able to offer technical assistance and training, either on-site or at its Training Centre in Dubai Page 2 of 3 constructive solutions 1.0 Surface preparation Attention to full and proper preparation of the substrate is essential for complete repair adhesion. 1.1 The surface of the substrate should be thoroughly cleaned to remove all traces of dust, oil, paint, curing compounds, grease, corrosion deposits, algae or any unsound material which might affect subsequent bond between Nitomortar FC and the substrate. 1.2 Oil and grease deposits are best removed by steam cleaning, detergent scrubbing or the use of a proprietary degreaser. 2.0 Mixing 2.1 Care should be taken to ensure that Nitomortar FC is thoroughly mixed to produce a fully homogeneous, trowellable mortar. 2.2 The hardener and base components should be stirred thoroughly in order to disperse any settlement before mixing them together. 2.3 The entire contents of the hardener and base can should be emptied into the mixing vessel and thoroughly mixed for 3 minutes. 2.4 Under no circumstances should part bags be used. 3.0 Application 3.1 Due to the easy workability of the product, the mixed material can be taken directly from the mixing vessel or subdivided onto spot boards for individual applicators. 3.2 Apply the mixed Nitomortar FC to the substrate using any of the application instruments; such as trowel, scraper, filling knife and squeegee. 3.3 Nitomortar FC can be overcoated with epoxy coatings after a minimum curing period of 24 hours. 4.0 Cleaning 4.1 Nitomortar FC should be removed from tools with Fosroc Solvent 102, immediately after use. Section B : Application Method Page 3 of 3 constructive solutions This method statement is offered by Fosroc as a ‘standard proposal’ for the application of Nitomortar FC. It remains the responsibility of the Customer to determine the correct method for any given application. Where alternative methods are to be used, these must be submitted to Fosroc for comment, in writing, prior to the commencement of any work. Section C : Approval and variations
